Stainless Steel Single Cartridge Filter Housing is manufactured by SS304 or SS316L, due to wide chemical compatibility, high temperature endurance and durability, SS single filter housing is particularly recommended for processes requiring high temperature which is not accepted by plastic filter housing. The water filter cartridges installed in SS single cartridge housing is available in standard and big blue sizes for different length. Stainless steel single cartridge filter housing offer economic and efficient alternatives for domestic, commercial and industrial water filtration. SS single filter housing is easy to install and maintain, high flow rate and long service life.
| Specification | |
|---|---|
| Material | SS304, SS316L |
| Surface Treatment | Polished, Sandblast |
| Cartridge Length | 5", 10", 20", 30", 40" |
| Cartridge Size | OD 2.5", 4.5" |
| No. of Cartridge | 1pc |
| Connection | BSPF, NPTF |
| Inlet/Outlet | 1/2", 3/4", 1" |
| Sealing Type | Thread, Clamp |
| Seal Material | EPDM, Silicon, Viton |
| Cartridge End Cap | DOE, SOE |
| Bottom | Flat Bottom, Drain with Plug |
