CDUNO Series Stainless Steel Sanitary Multi Cartridge Filter Housing is composed of a microporous membrane pleated filter element and a sanitary 304 or 316L stainless steel housing, SS sanitary cartridge housing is equipped with a multi cartridge filters. SS sanitary multi cartridge housing is connected by a quick-fit clamp or quick-opening ring bolt, which is convenient for loading and unloading the filter element and cleaning the filter. The inner surface of sanitary multi cartridge filter housing is mirror polished (roughness Ra≤0.3μm). The inside and outside of SS sanitary multi cartridge housing are finely polished, and there is no dead corner. Sanitary cartridge housing is small size, light weight, easy to use and clean, large filtration area, low clogging rate, high filtering speed, good thermal dilute stability and chemical stability. Stainless steel sanitary cartridge housing is widely used in fine filtration and sterilization processes.
| Specification | |
|---|---|
| Housing Material | SS304, SS316L |
| Vent Vale/Drain Valve | SS304 |
| Finish Type | Polishing |
| Polishing Precision | 0.3µm inner surface, 0.4µm outside surface |
| Cartridge Length | 10", 20", 30", 40" |
| Cartridge Size | OD 2.5" pleated filter |
| No. of Cartridge | Multiple Cartridges |
| Connection | Swing Bolts, Clamp |
| Inlet/Outlet | Thread, Flange |
| Seal Material | EPDM, Silicon, Buna N, Viton |
| Cartridge End Cap | 222 O-ring, 226 O-ring |
