Stainless Steel Multi Cartridge Filter Housing is manufactured by high quality SS304 or SS316L stainless steel and workmanship. SS multi filter housing accommodate different end cap styles of filter cartridges in either DOE or SOE, providing economic and efficient alternatives of filtration processes. SS multi cartridge filter housing is suitable for a wide variety of filtration applications requiring high temperature and operating pressure. Filter elements installed inside SS multi cartridge housing are change out quick and easy while ensuring good sealing performance. SS cartridge filter housing is widely used for many industrial and commercial micron filtration systems.

Specification
Material	SS304, SS316L
Surface Treatment	Polished, Sub-polished, Sandblast
Cartridge Length	10", 20", 30", 40"
Cartridge Size	OD 2.5"
No. of Cartridge	Multiple filter elements
Connection	Thread, Flange
Inlet/Outlet	1", 1.5", 2", 4" etc.
Sealing Type	Swing Bolts, Clamp
Seal Material	EPDM, Silicon, Viton
Cartridge End Cap	DOE, SOE

Features:

Stainless steel filter housing is easy to install, maintain and clean, convenient and efficient for change cartridge filters
SS multi cartridge housing is suitable to work under high pressure and no fluid leakage, safe and reliable long service life
SS multi cartridge filter housing is made of high quality stainless steel, surface treatment with electrolytic polishing or matt
SS multi cartridge filter housing is large filtration area, high flow rate and low plugging rate, strong resistance to acid and alkali

Applications:

RO Prefiltration
Food & Beverage
Medical and Chemical
Petrochemical Industry
Household Water Filtration
Industrial Wastewater Treatment

Performance
Max. Temperature	130℃
Max. Pressure	10 Bar (150psi) or according to requirement
Recommended Pressure	≤ 8 Bar (115psi) at 25℃

Stainless Steel Multi Cartridge Filter Housing Production Display

Accepts complete range of filter cartridges with 222/226/DOE end caps
Food-grade design, no sanitary dead corners, can be completely disassembled and clean
We offer up to 50 rounds cartridge housing for all industrial needs application with unique spring aided design
Ergonomic and easy-to-use cover closure, quick-opening design, competent for strict application requirements
Suitable for RO plants, water treatment plants, wastewater recycling, petrochemicals, plating solutions with high water pre-filtration.

Stainless Steel Multi Cartridge Filter Housing

Features:

Stainless steel filter housing is easy to install, maintain and clean, convenient and efficient for change cartridge filters

SS multi cartridge housing is suitable to work under high pressure and no fluid leakage, safe and reliable long service life

SS multi cartridge filter housing is made of high quality stainless steel, surface treatment with electrolytic polishing or matt

SS multi cartridge filter housing is large filtration area, high flow rate and low plugging rate, strong resistance to acid and alkali

Applications:

RO Prefiltration

Food & Beverage

Medical and Chemical

Petrochemical Industry

Household Water Filtration

Industrial Wastewater Treatment

Stainless Steel Multi Cartridge Filter Housing Production Display

Accepts complete range of filter cartridges with 222/226/DOE end caps

Food-grade design, no sanitary dead corners, can be completely disassembled and clean

We offer up to 50 rounds cartridge housing for all industrial needs application with unique spring aided design

Ergonomic and easy-to-use cover closure, quick-opening design, competent for strict application requirements

Suitable for RO plants, water treatment plants, wastewater recycling, petrochemicals, plating solutions with high water pre-filtration.
